Abrasives: Types & Classification

Summary:

Abrasives are important tools for cutting, grinding, polishing, and finishing workpieces by removing material through friction.

Abrasives can be divided into two main categories: natural abrasives, such as diamond and sand, and synthetic abrasives, which include materials such as silicon carbide and aluminum oxide. Synthetic abrasives are further classified into bonded types, such as grinding wheels, and coated types, such as sandpaper.

Common types of abrasives include cut-off wheels, grinding wheels, sanding paper, polishing pads, flap discs, cutting blades, buffing wheels, and more, each of which is designed for specific tasks.

Choosing the right abrasive involves considering factors such as the hardness and toughness of the material, as well as the size of the workpiece. The purpose of this guide is to clarify the classification and assist users in choosing the most appropriate abrasive for their projects.

Abrasive is a tool that gives fine shape, polish, and design to every workpiece. The friction wears away a portion of the workpiece while doing this. A workpiece can also be detailed or polished to provide a smooth, polished, and silky surface.

 In other words, an abrasive is a kind of ceramic that is used for cutting, grinding, and polishing. Abrasives have wide applications in commercial and domestic needs. In addition to cutting and grinding, individuals can use these abrasives to buff, hone, drill, sharpen, lap, and sand. Now, let’s proceed toward the types of abrasives:

Types of Abrasives

Abrasives are mainly divided into two categories- Natural & Synthetic. The synthetic abrasives are then divided into two subcategories: bonded and coated abrasives. Here are some examples of natural and artificial abrasives:

• Natural Abrasives - Diamond, calcite, iron oxide, sand, sandstone, and feldspar powder.

• Synthetic Abrasives -Steel abrasive, silicon carbide, glass powder, ceramic, aluminum oxide, slags, and Borazon.

• Bonded Abrasives - These abrasives are composed of an abrasive material that is contained within the matrix.

• Coated Abrasives - Paper, cloth, and other backing materials are used in these abrasives. It is covered with abrasive materials to provide perfection in coated abrasive uses.

Classification of Abrasives

Abrasives are classified into broad categories. Below is a detailed structure for the classification of abrasives.

1. Cut-off Wheel Abrasive

The cut-off wheels are also recognized as self-sharpening abrasives. Cut-off wheels are mainly used for hard materials such as metal, stone, concrete, etc. It is known as a cutting tool and perfection and has a long life as well. These wheels are ideal for processing, servicing, repair, and general industrial applications of metals.

2. Mounted Point Abrasives

Mounted point abrasives are little grinding wheels that are bonded over a mandrel. It comes in various shapes and sizes, with abrasive grains, rubberized plastic, and felt.

In the manufacturing process, mounted point abrasive is used primarily for deburring applications. It is ideal for detailing and finishing, including in machine gears and congested areas. A die grinder, straight shaft grinder, or hand-held rotary tools are paired with it.

3. Sanding Paper (SandPaper Sheets)

Sanding paper is also classified as glass paper. It removes stock from wood, metal, or any other surfaces and makes them smooth for coloring and polishing. Sandpapers are capable of removing old oil paint and glue. You may use the sandpaper sheets for both industrial purposes as well as DIY activities.

They are suitable for both hand sanding and power sanding. The most common forms of sanding paper are Emery, Zirconium Alumina, Ceramic Alumina, Aluminum oxide, and garnet.

4. Grinding Wheel Abrasive

The grinding wheel is made up of an abrasive compound used for grinding processes, abrasive cutting, and abrasive machining. It is mainly designed for grinding machines. Grinding wheels are either made of aluminum or solid steel. Straight wheels, cylinder rings, tapered types, dish cups, diamond-type, cut-off types, and types of saucers are common forms of grinding wheels. Using different bonding materials like resinoid, silicate, rubber, and metal, abrasive grains are held together in the machine.

5. Diamond Grinding Cup Wheels

Diamond grinding cup wheels are metal-bonded stone tools with a welded or cold-pressed diamond section on a wheel body. Grinding materials like concrete, granite, and marble are typically placed on concrete grinders. Often, it has double-row segments for quick material removal. For both wet and dry concrete grinding, leveling, or concrete removal, cup wheels are necessary.

6. Sand & Fiber Discs

The sanding disc is a circular sand disc perfect for wood, metal, or plastic surfaces to remove material, light flaws, corrosion, paint, and rust. It has a coarse grain that helps extract metal welds, wood mill traces, and even the edges.

7. Fiber disc

A fiber disc is a grinding wheel made of vulcanized fiber along with backing. It is covered with resin and abrasive grains on one side. It is fitted with a backing pad, and an angle grinder is attached. The fiber disc is widely used for machining metals.

8. Polishing Pads

Polishing pads are used to remove small car and truck scratches and dents. Usually, it is used to buff out the damage and add shine to the surface. They come in various finishes, forms, designs, and sizes. To get optimal results, the pad should be used with the polishing compound.

9. Flap discs Abrasive

Flap discs are used explicitly for the finishing of metals, welding, machining, and industrial maintenance. It consists of numerous overlapping small pieces of flaps connected to a central hub. The flaps are made of polyester or polycotton. Form, backing plate content, flap density, and flap grit size are the different parameters to consider when selecting the flap disc.

10. Cutting Blades and Discs

Cutting blades are widely used for the cutting process. Cutting blades are perfect for cutting different materials such as wood, metal, and stony minerals. Depending on the form of the edges, it can be defined.

11. Cutting Disc

A cutting disc is a flexible tool for cutting numerous materials using an angle grinder. It is about a small and flat disc that has synthetic resin as a binder.

12. Abrasive Papers

Abrasive paper is glass paper used as an abrasive coating form, consisting of a sheet of paper or fabric, fiber, film, or another abrasive material backing. The standard abrasive particles are aluminum oxide and silicon carbide. Such abrasive paper is used to deburr, polish, remove ink, remove rust, resize, etc.

13. Cloth Rolls

Cloth rolls are perfect for flexible and quick cutting. It can be cut to the appropriate length in intricate areas for removal, blending, and finishing applications and provides hand-sanding ability. In the industrial sector (production) and craft market, fabric rolls have broad applications. Cloth rolls give the workpiece a smooth and silky finish. It can support extreme use as well as being durable. It has a synthetic bonding resin that boosts the life of the roll.

14. Buffing Wheels

Buffing wheels are also recognized as polishing wheels. It is used to finish several workpiece materials with scratches & dents. Perfect to use on flat surfaces as well as curved surfaces. It provides a smooth and luminous texture. The wheel consists of different layers of soft materials such as cotton, flannel, etc. It has an internal mounting hole for the arbor or an incorporated shank.

15. PVA Sponges

PVA sponges are formed of synthetic material that prevents both mildew & mold. A PVA sponge is ideal for absorption compared to a regular sponge or sheet. It has high absorption power and, therefore, provides a fast and efficient drying process. On all surfaces, it eliminates water spots. The PVA sponge expands during absorption and dries during compression.

How to select the right abrasive?

The following are the factors to be considered when selecting the right abrasive:

• Material’s hardness: Selecting the right abrasives will depend on the material's hardness and softness. Hard materials, including ceramics, hard steel, glass etc., require abrasives that are hard and effectively cut or grind. These abrasives are capable of withstanding excessive pressure and resisting deformation. On the other hand, softer materials, including wood, soft metals, etc, require softer abrasives like garnet or aluminum oxide.

• Material’s toughness: materials' toughness will also help in selecting the right abrasives. Toughness refers to the abrasive ability to withstand high pressure without any fracturing or breaking. Abrasives that have high fracture toughness are suitable for working with tough materials. This will help the abrasive maintain its original shape and cutting edges during the process, which will result in efficient material removal and increased lifespan.

• The shape of a workpiece: The shape of a workpiece is also a crucial factor to consider before choosing the right abrasives. Complex shapes require flexible abrasives, including coated abrasive sandpaper. These are flexible abrasives and can easily work in delicate areas. On the other hand, simple shapes require more rigid abrasives like grinding wheels. It produces more accurate results compared to complex shapes.

Conclusion:

The article aims to simplify the classification of abrasives. It gives you a brief explanation of every type of abrasive, along with their applications as well.  This article will save you time and the effort you put into research work to find the right type of abrasive.
