Different Types of Tungsten Electrodes

Different Types of Tungsten Electrodes

Tungsten welding electrodes cannot be destroyed during the welding process as they aren't dissolved into the weld pool. Extraordinary consideration should not allow the electrode to contact the welding pool to stay away from weld pollution. This would be alluded to as tungsten consideration and may bring about weld disappointment. Terminals will regularly contain little amounts of metallic oxides, which can offer the accompanying advantages:

  • Assist in bend beginning.
  • Improve current conveying limit of the electrode.
  • Reduce the danger of weld pollution.
  • Increase electrode life.
  • Increase weld security.

Different Types of Tungsten Electrodes

Rare Tungsten Electrodes

These TIG electrodes are unalloyed, 'rare' tungsten with a 99.5% tungsten least and are generally minimal. They give great curve strength when utilizing AC, with either adjusted wave or unequal wave and consistent high-recurrence adjustment.

Pure tungsten electrodes or Rare tungsten electrodes are liked for AC sine wave welding of aluminum and magnesium since they furnish great bend dependability with both argon and helium protecting gas. The rare tungsten terminal effectively frames a balled end yet tends to spit at higher flows, and this ought to be viewed when making basic welds.

2% Ceriated Tungsten Electrodes

These TIG electrodes are alloyed with about 2% ceria, a non-radioactive material, and the most bountiful uncommon earth components. The expansion of this little level of cerium oxide expands the electron outflow characteristics of the electrode, which gives them a superior beginning trademark and a higher current conveying limit with no spitting.

These are universally handy terminals that will work effectively with AC or DC electrode negative. Contrasted and rare tungsten, the ceriated tungsten electrodes accommodate more prominent bend soundness. They have phenomenal curve beginning properties at low current. Whenever utilized on higher current applications, the cerium oxide might be concentrated to the unreasonably hot tip of the terminal.

This condition and oxide change will eliminate the advantages of the cerium. The non-radioactive cerium oxide has marginally unique electrical properties when contrasted with the thoriated tungsten terminals. The cerium electrodes function admirably with the Advanced Squarewave power sources and should be ground to an altered point.

2% Lanthanated Tungsten Electrodes

These TIG electrodes are alloyed with non-radioactive lanthanum oxide, frequently alluded to as lanthanum, one of the uncommon earth components. These terminals have incredible bend beginning, low disintegration rate, curve dependability, and fantastic re-start attributes.

Expanding 1 – 2% lanthana expands the greatest current conveying limit by around half for a given size terminal utilizing rotating current contrasted with rare tungsten. The higher the level of lanthana, the more costly the terminal. Since lanthana terminals can work at marginally unique bend voltages than thoriated or ceriated tungsten electrodes, these slight changes might require changing welding boundaries and methods.

The lanthana is scattered uniformly all through the whole length of the electrode, and it keeps up with a honed point well, which is a benefit for welding steel and treated steel on DC or the AC from Advanced Squarewave power sources. Accordingly, the 2% lanthanated tungsten electrodes function admirably on AC or DC electrode negative with a sharp end, or they can be balled for use with AC sine wave power sources.

2% Thoriated Tungsten Electrodes

Thoriated electrodes, both 1 and 2% are ordinarily utilized electrodes since they were quick to show better bend execution over rare tungsten for DC TIG welding. Be that as it may, thoria is a low-level radioactive material; along with these lines, fumes, granulating residue, and removal of thorium raise wellbeing, security, and ecological concerns.

The moderately limited quantity present has not been found to address a wellbeing peril. Be that as it may, if welding will be done inbound spaces for delayed timeframes, or then again if terminal crushing residue may be ingested, uncommon precautionary measures ought to be taken concerning appropriate ventilation. The welder ought to counsel an educated security workforce and find suitable ways to avoid the thoria.

These terminals are generally liked for direct current applications. In numerous DC applications, the terminal is ground to a shape or pointed. The 2% thoriated tungsten electrodes will hold the ideal shape in those applications where the rare tungsten would liquefy back and structure the ball end. The thoria content in the electrode is liable for expanding the existence of this sort over the rare tungsten.

Zirconiated Tungsten Electrodes

This TIG tungsten is alloyed with zirconium oxide (zirconia). It is liked for AC TIG welding when the best work is vital and where even the littlest measures of weld pool pollution can't go on without serious consequences. This is refined because the zirconium alloyed tungsten delivers an amazingly steady circular segment that opposes tungsten spitting in the curve.

The current conveying ability is equivalent to or somewhat more prominent than an equivalent measured cerium, lanthana, or thorium alloy electrode. Zirconium electrodes are regularly utilized uniquely for AC welding with a balled end.

The tungsten electrodes arrive in an assortment of breadths, and you would choose the proper distance across for the current to be utilized and type for the cycle mode. To truly distinguish the tungsten type, the end is plunged with a shading.
