Grinding And Finishing Metal With Flap Discs

It is crucial to use the right product for the job in any metal grinding or finishing application since it lowers the risk of removing too much material and shortens the process's time and expense. Flap discs are frequently a useful option when working with thinner materials. Flap discs enable more delicate blending and finishing tasks while still providing dependable grinding action.

The same grain types used in bonded abrasives are used in the creation of flap discs, but because of their layered design, they have a much softer, more forgiving feel. They are, therefore, perfect for simultaneously grinding and finishing a product, which helps save time and money. However, they are less effective at polishing coarser surfaces that call for more forceful action, such as slag from a torch. The flap disc's material can catch and rip too readily, so a grinding disc would be more appropriate in this situation.

Coated abrasives on these flap discs hold grains to a backing cloth, usually cotton, polyester, or a combination of materials. The flap disc is created by cutting this abrasive cloth into smaller flaps and layering them radially.

The abrasive substance and grit size utilized, as well as how well a flap disc functions, are all important factors. The three main cutting grains are zirconia alumina, ceramic alumina, and aluminum oxide.

As the grains run out, the flaps wear away, revealing new, sharp grains below. A flap disc can be used until the material is entirely worn down to the rear plate when used properly.

Flap discs are typically made to be used on right-angle grinders at angles ranging from 5 to 35 degrees. For finishing and applications requiring lower grinding angles between 5 and 15 degrees, a Type 27 flap disc works best. For more forceful, higher-angle grinding between 15 and 35 degrees, a Type 29 flap disc is recommended.

It can be challenging to select the flap disc with the highest performance and longevity for the task at hand. Take into account these three important factors before making your final decision:

• The time, productivity, and efficiency requirements
• The intended aesthetics and surface polish
• Labor and consumable expenses

THE OPTIMUM GRAIN AND DISC SIZE SELECTION

It is crucial to select grains and grit that are suitable for the purpose and the metal being cut, respectively. Making the proper decision requires taking into account the goals and priorities for the final weld. Generally speaking, use the highest grit that will complete the task in order to guarantee a great finish.

There are high-density — or jumbo—flap discs in addition to standard-density flap discs. These flap discs are thicker, softer, and more durable since they have more material covering them. The greatest option for grinding on curved or uneven surfaces is high-density flap discs.

Additionally, flap discs are produced in a variety of sizes, from 2 to 7 inches. A 2-inch disc can use up to 15 times as much energy as a blending disc and can effectively replace it. The overall cost of use can be greatly decreased, and the immediate and dramatic impact of fewer product changes can be felt.

SELECTING THE ABRASIVE SUBSTANCE

The most popular flap disc used today is zirconia alumina, while aluminum oxide is frequently chosen when a reliable, affordable product is required. This kind of flap disc, which is made up of a mixture of zirconia alumina and aluminum oxide grains, offers the greatest adaptability at the lowest possible cost. Although it initially costs a little more than an aluminum oxide flap disc, it has better heat resistance, is more robust and durable, and keeps its sharpness for a longer period.

Ceramic alumina is the third option for an abrasive substance. These flap discs' grains microfracture to create an endless supply of the sharpest edges and they are also more heat-resistant. The most expensive choice is ceramic alumina flap discs, but they also have the longest lifespan of the three. When choosing the right abrasives for your application, keep an open mind.

The operator must weigh factors like the decrease in downtime for changeover and the reduction in inventory for extra items when deciding if the longer longevity of a ceramic flap disc is worth the additional cost. When these factors are taken into account, the more expensive ceramic flap disc frequently offers the lowest overall cost of use.

Finding the flap disc that fulfills the requirements of the application while staying within the necessary schedule and budget is the ultimate objective.

USING THE APPROPRIATE METHOD

It's crucial to apply the right pressure at the right angle in order to maximize the efficiency and durability of a flap disc.

When a flap disc cannot function quickly enough, applying too much pressure to it can result in gouging, undercutting, heat accumulation, and color fading, in addition to premature wear. Consider a coarser grain if you discover that you need to exert more force to get a disc to work. Additionally, applying too much pressure might undercut, gouge, or harm the workpiece. Maximum tool speed is required for premium cutting grains like ceramic and alumina. In fact, excessive pressure might make the grinder "bog down," which lowers the rate at which the grain is sliced. The grain may also get dull or glaze over, which reduces the disc's ability to cut. When this occurs, the disc must be thrown away, regardless of how much of it has been consumed.

The operator has to work significantly harder when grinding at too steep an angle since they need to utilize the entire breadth of the cloth. The flap overhang is subjected to greater strain and stress as a result of steep grinding, which might shorten the product lifespan.

Avoid removing too much metal while completing thin weld material, in particular, to avoid creating a weak spot. Another strong reason to use the least aggressive disc for the work is because it will allow for tighter tolerances. The workpiece may be ruined if the thin material is undercut or gouged. It is typically preferable to utilize a higher grit than a 36- or 40-grit disc in applications where these problems are actual considerations. Examples of such higher grits are 60 and 80.

Don't try to determine whether a disc has been fully used based on flap wear when using flap discs. Flap discs are intended to be used until adhesive is visible through the flap. A flap disc will keep cutting when used properly until adhesive is apparent. When shared with all operators, this one idea has the potential to reduce product costs by a sizable amount.

Though flap discs are disposed of after use, some methods can be performed to extend their usefulness. Less downtime, more productivity, and higher savings are the outcomes.
