Product Specification
4” x 5/8”-11 THREADED DOUBLE ROW DIAMOND GRINDING CUP WHEEL
Built for surface grinding, leveling, and stock removal, the Benchmark Abrasives 4” Double Row Diamond Grinding Cup Wheel is designed for concrete, granite, marble, masonry, and natural stone. Its compact size gives operators excellent control for localized grinding, edge work, high-spot removal, and surface correction on hard mineral materials.
The 4” wheel uses 5 mm diamond segments and a direct-thread 5/8"-11 UNC hub for mounting on compatible grinding equipment. Rated up to 13,580 RPM and approved for wet or dry grinding, it is a versatile option for concrete preparation, renovation, restoration, and stone work.
Product Specifications
| Specification |
Details |
| Diameter |
4" |
| Wheel Type |
Double Row Diamond Grinding Cup Wheel |
| Operation |
Surface Grinding |
| Diamond Segment Height |
5 mm |
| Arbor |
5/8"-11 UNC Threaded |
| Maximum RPM |
13,580 RPM |
| Grinding Method |
Wet or Dry |
| Quantity |
1 Wheel |
Features
- Double row diamond grinding cup wheel for surface preparation
- Designed for leveling and stock removal on hard mineral surfaces
- 5 mm diamond segment height
- Compact 4" diameter for controlled grinding in smaller areas
- Direct-thread 5/8"-11 UNC mounting
- Rated up to 13,580 RPM
- Suitable for concrete, granite, marble, masonry, and natural stone
- Wet or dry grinding capability
- Useful for removing high spots and correcting uneven surfaces
- Designed for surface grinding rather than cutting
Applications & Performance
Designed for grinding, leveling, and material removal on hard masonry and stone surfaces.
- Concrete surface leveling
- Removing high spots
- Smoothing uneven concrete
- Masonry surface preparation
- Granite grinding
- Marble grinding
- Natural stone surface preparation
- Edge and localized grinding
- Surface correction before coatings or finishing
- Construction and renovation work
The double row format is intended for general-purpose surface grinding and stock removal where controlled material removal and consistent contact with the work surface are important.
Materials
- Concrete
- Granite
- Marble
- Masonry
- Natural Stone
Machine Compatibility
For use with 4” angle grinders.
Compatible examples include:
-
Milwaukee® 6117-33D Angle Grinder — 11,000 RPM maximum; 5/8"-11 threaded mounting with the manufacturer’s 4"/5" surface-grinding dust shroud. For dry grinding.
Other models may also fit. Match the mounting, speed rating and required guard to your tool.
Safety Tips
- Never exceed the wheel’s maximum rated speed of 13,580 RPM.
- Inspect the diamond segments, steel body, and threaded hub before each use.
- Do not use a cracked, damaged, bent, or excessively worn cup wheel.
- Confirm the grinder uses the correct 5/8"-11 threaded spindle.
- Thread the cup wheel fully and securely onto the spindle according to the machine manufacturer’s instructions.
- Use a guard or dust shroud designed for diamond cup-wheel grinding.
- Maintain controlled contact with the work surface and avoid excessive pressure.
- Do not use this cup wheel as a cut-off blade.
- Wet or dry grinding is permitted only when the machine is also approved for the selected method.
- Use appropriate eye, hearing, respiratory, hand, and other required personal protective equipment.
- Grinding concrete, masonry, granite, marble, and other silica-containing materials can generate respirable silica dust. Use appropriate water-delivery or dust-extraction controls.
