SA-5 NF Aluma Cut Cylinder Shape Premium Tungsten Carbide Burr

• Product Specification
• Shipping
• Refund

Product Specification

SA-5NF CYLINDER SHAPE PREMIUM TUNGSTEN CARBIDE BURR– ¼” shank

SA-5NF Cylinder shape burrs are great for interior contour work and deburring. Due to the extreme hardness of this tungsten carbide, it can be used on much more demanding jobs than HSS (High-Speed Steel). These carbide burrs are made of tungsten carbide burr die grinder bits and will start to soften at higher temperatures, so carbide is always the best choice for long-term performance.

Aluminum cut carbide burrs tend to be used on non-ferrous metals like aluminum, copper, zinc alloys and magnesium as well as for non-metal materials such as plastics, hard rubber, and some woods. These carbide burrs are specially designed for fast stock removal without loading. Design allows chips to flow out of the flutes. Use for medium stock removal, deburring, finishing, and cleaning.

Quantity: 1 piece

Dimensions:

• Head Shape – Cylinder Shape
• Head Diameter – 1/2"
• Length of Cut – 1”
• Shank Diameter – 1/4”
• Overall Length – 2-3/4”
• Cut – Aluminum cut
• Max RPM – 70,000, however it is uncommon to need more than 35,000 RPM.  Click here to see our recommended operating speeds by application and size.

Machines Used On:

• Die Grinders and hand-held pneumatic grinders

Application:

• Non-Ferrous Materials – Aluminum, Copper, Zinc alloys, Magnesium
• Other Materials – Plastic, Hard Rubber, Soft Wood
• Cylinder Shape burrs are great for interior contour work like peripheral and face milling.

Safety Tips & Techniques:

• Tool speed will be determined by the material you are using your burr on. If you are experiencing chipping, you are most likely operating at too high of speed for the application. Start with a slower speed and increase as you go along until you achieve the best results
• Apply light pressure and let the tool do the work. Bearing down on the tool will result in reduced tool life and a dull burr.
• Always wear proper PPE to include (but not limited to) safety glasses, hearing protection, respirator, and hand protection.  Keep all guards in place on your machine.
• Avoid use on electric power drills; the slower speeds can result in chipping of your workpiece.
