SC-5 WOOD CARVING TUNGSTEN CARBIDE ROTARY BURR

The SC-5 wood carving tungsten carbide rotary burr is built for fast, controlled stock removal on compatible 4-1/2" to 5" angle grinders. Its narrow 1/2" cylinder-shaped head with a radius end and extended 2" cutting length make it especially effective for reaching deeper grinding areas, shaping narrow recesses, hollowing cavities, and handling detailed contour work where a broader carving burr cannot reach as easily.

A 5/8"-11 direct-thread mount installs directly onto the grinder spindle with no adapter or collet required. The structured tungsten carbide teeth remove material quickly while the long, narrow profile gives you greater access into recessed areas and complex contours while maintaining control over depth and shape. Designed for early-stage carving and rough forming, the SC-5 works across softwoods, hardwoods, and foam before transitioning to sanding or surface-finishing abrasives.

Product Specifications

Features

• 1/2" cylinder-shaped head with radius end for narrower shaping and detailed contour work.
• 2" cutting length provides a long working surface for shaping recesses and contours.
• Tungsten carbide cutting surface designed for aggressive rough material removal.
• 5/8"-11 direct-thread mount installs directly onto compatible angle grinders.
• Narrower profile provides access to tighter spaces than the wider SC-8.
• Rounded end supports concave shaping, recesses, and curved transitions.
• Designed for rough shaping and initial forming before sanding and finishing.
• Use with light pressure and controlled passes for better tool control.

Applications

The SC-5 profile is particularly useful for:

• Narrow recesses and cavities
• Narrow concave areas
• Hollowing bowls and carved forms
• Detailed rough shaping and contouring
• Freehand wood carving
• Sculpting and rough forming
• Reaching complex or recessed contours
• Foam shaping and modeling
• Preparing carved surfaces for subsequent sanding

Materials

Suitable for rough shaping on:

• Softwoods: Pine, spruce, cedar
• Hardwoods: Oak, maple, beech
• Foam

Machine Compatibility

Designed for compatible 4-1/2" to 5" angle grinders using a 5/8"-11 threaded spindle with a maximum rated speed of 15,000 RPM or less.

Compatible examples include:

• Benchmark Abrasives 4-1/2" Corded Angle Grinder - 5/8"-11 spindle thread, 11,000 RPM
• Makita® 9557PB - 5/8"-11 spindle thread, 11,000 RPM
• Makita® 9564CV - 5/8"-11 spindle thread, 2,800-10,500 RPM
• Bosch® GWS8-45 - 5/8"-11 spindle thread, 11,000 RPM

Check the exact grinder's instructions, thread engagement and guard clearance before use.

Safety Tips

• Never exceed the 15,000 RPM maximum.
• Use the burr dry only.
• Apply light pressure and allow the carbide cutting surface to remove material. Excessive pressure can reduce tool life and control.
• Make controlled passes rather than forcing the burr deeply into the workpiece.
• Secure the workpiece before beginning.
• Verify that the burr is properly seated and securely threaded onto the grinder.
• Keep all required machine guards in place and ensure adequate accessory clearance.
• Always wear appropriate PPE, including safety glasses, hearing protection, respiratory protection, and hand protection.
• Do not use on electric drills, small rotary tools, or machines with incompatible mounting systems.
• This is a rough-shaping tool. Follow with appropriate sanding abrasives to achieve the desired final surface.
